VTH5421HW(B)-W
IP & Wi-Fi Indoor Monitor
> 7" TFT capacitive touchscreen, 1024 × 600
> 6-channel alarm input and 1-channel alarm output
> Wi-Fi
> Door station and IPC monitor
> H.265 and H.264 video decoding
> High performance & cost-effective
Product Data
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor |
Embedded processor |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System |
Embedded Linux operating system |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF; SDK |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol |
RTSP; RTP; SIP; DNS; SSH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Type |
Capacitive touchscreen |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display |
7" TFT |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Resolution |
1024 × 600 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711a; G.711u; PCM |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
Built-in speaker |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Mode |
2-way Audio |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Enhancement |
Echo suppression |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Bit Rate |
16 kHz; 16 Bit |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Mode |
Full digital |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Information Release |
Receive and view text information released by the management center |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Leave Videos |
Yes (insert an SD card into the indoor monitor) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DND Mode |
Do not disturb period can be set; Do not disturb mode |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Number of Extensions |
Villa: 9 Apartment: 4 Wi-Fi intercom: 1 main monitor, 2 extension monitors |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wi-Fi |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless Standard |
IEEE802.11b/802.11g/802.11n |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless Frequency Range |
2.4 GHz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
Micro SD card (up to 64 GB) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless Security Encryption |
WPA/WPA2; WPA-PSK/WPA2-PSK |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing |
PC + ABS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input |
6 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Output |
1 (12 V/200 mA) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Door Bell |
Yes (use any alarm input port) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
One 10 /100 Mbps Ethernet |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Appearance Color |
White/Black |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
12 VDC 1 A Standard PoE (36–57 V, 0.35 A) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation |
Surface mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE; FCC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
–10 °C to +55 °C (+14 °F to 131 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10%-95% RH (non-condensing) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Altitude |
Beneath 3000 m (9842.52 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
Standby ≤ 2 W; working ≤ 6 W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.35 kg (0.78 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
0.56 kg (1.23 lb) |
