Dahua SDT6C432-4P-GB-APV-0280: A Revolutionary PTZ Camera for Enhanced Surveillance

April 14, 2025

The Dahua SDT6C432-4P-GB-APV-0280 is a cutting-edge PTZ camera designed to elevate surveillance capabilities across various applications. This camera combines advanced technology with innovative design to deliver exceptional performance in both challenging lighting conditions and complex monitoring scenarios. Whether deployed for perimeter protection, traffic monitoring, or public safety, this camera stands out as a versatile and reliable solution for modern security needs.

Key Features

Enhanced Monitoring Capabilities

The camera features a multi-sensor design with an additional lens, enabling it to quickly track targets while maintaining a comprehensive view of the monitored area. This dual-lens system ensures that no detail is missed, making it ideal for applications requiring both wide-area coverage and precise target tracking.

AI-Powered Intelligence

Equipped with an embedded AI chip and deep learning algorithms, the camera performs a wide range of intelligent functions. It supports face detection with attributes and expressions, perimeter protection with false alarm filtering, and auto-tracking for seamless monitoring. These capabilities enable users to act swiftly on defined targets, enhancing overall security efficiency.

Superior Image Quality

Using industry-leading wide dynamic range (WDR) technology, the camera produces vivid images even in high-contrast lighting conditions. It adjusts seamlessly between bright and low-light environments, ensuring superior video quality. The Starlight technology further enhances low-light performance, capturing clear images in near-dark conditions.

Versatile Applications

The camera is suitable for a variety of scenarios, including perimeter protection, traffic monitoring, and public safety. Its ability to filter out false alarms caused by environmental factors like animals or leaves ensures accurate and reliable alerts, reducing unnecessary interventions.

Technical Specifications

Image Sensor: Panorama: 1/2.8" CMOS, Detail: 1/2.8" CMOS
Pixel: Panorama: 4 MP, Detail: 4 MP
Max. Resolution: Panorama: 3840 × 1080, Detail: 2560 × 1440
Optical Zoom: Detail: 32×
IR Distance: Detail: 200 m (656.17 ft)
Auto-tracking: Yes
Perimeter Protection: Yes
Face Detection: Yes
Protection Rating: IP66
Sound and Light Alarm: Yes
180° Panoramic Splicing: Yes

PTZ Capabilities

Pan/Tilt Range: Detail: H: 0°–360° endless, V: –20°–+90°
Manual Control Speed: Detail: Pan: 0.1°/s–160°/s, Tilt: 0.1°/s–120°/s
Preset Speed: Detail: Pan: 240°/s, Tilt: 200°/s
Preset: 300
Tour: 8 (up to 32 presets per tour)
Pattern: 5
Scan: 5
Power-off Memory: Yes
Idle Motion: Pattern; Preset; Scan; Tour

Video and Audio

Video Compression: H.264H; H.264B; Smart H.265+; H.265; MJPEG (Sub Stream); Smart H.264+; H.264M
Streaming Capability: 3 streams
Resolution: Panorama: 3840 × 1080; 960 × 268; D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240); Details: 2560 × 1440 (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Audio Compression: PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723

Network and Environment

Network Port: RJ-45 (10/100 Base-T)
Network Protocol: FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTSP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; QoS
Interoperability: CGI; ONVIF (Profile S&G&T)
User/Host: 20 (total bandwidth: 64 M)
Storage: FTP; Micro SD card (up to 512 G); NAS
Browser: IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; iOS 10 and later versions
Management Software: DMSS; DSS Pro
Mobile Client: iOS; Android
Certification: CE: DHQA-ESH-P22100890/DHQA-ESHP22100654B-A1

Power and Environment

Power Supply: 36 VDC/2.23 A ± 25%
Power Consumption: Basic: 20 W, Max: 35 W (IR + heater + intelligent functions + PTZ working)
Operating Temperature: –40 °C to +65 °C (–40 °F to +149 °F)
Operating Humidity: ≤95%
Protection: IP66
Casing Material: Plastic, aluminum alloy
Product Dimensions: 247 mm × 202 mm × 359.8 mm (9.72" × 7.95" × 14.17") (L × W × H)
Net Weight: 5.3 kg (11.68 lb)
Gross Weight: 7.12 kg (15.70 lb)

Applications

The DH-SDT6C432-4P-GB-APV-0280 is ideal for applications requiring high-resolution imaging, intelligent analytics, and reliable performance. Whether deployed in urban surveillance, traffic monitoring, or perimeter protection, this camera ensures comprehensive coverage and accurate detection. Its advanced features make it a versatile solution for both indoor and outdoor environments.

Accessories

The camera comes with a comprehensive range of accessories to facilitate installation and customization:

DC36V/2.23A Power Adapter
PFA114 Mount Adapter
PFB303W Wall Mount Bracket
PFB300C Ceiling Mount Bracket
PFA150 Vertical Pole Mount Bracket
PFA151 Corner Mount Bracket
PFA150 + PFB300C Horizontal Pole Mount Bracket
PFB301S-E Plane Mount Bracket
PFB303S Parapet Mount Bracket

High - Resolution Imaging

Equipped with a 1/2.8" 4Megapixel STARVIS™ CMOS sensor, this camera delivers sharp and clear images at a resolution of 2560 × 1440, ensuring every detail in the small - office environment is captured with precision. Whether it's monitoring employee activities, protecting assets, or keeping an eye on the entrance, the high - resolution output provides actionable insights. In contrast, some similar Hikvision models might offer lower base resolutions, potentially missing out on crucial details.

32× Optical Zoom and Starlight Technology

The 32× optical zoom allows for close - up monitoring of specific areas within the office, such as document processing areas or cash registers. Additionally, the Starlight technology enables the camera to function effectively even in low - light conditions. This means that small offices can maintain round - the - clock surveillance without the need for excessive lighting, saving on energy costs. Compared to certain Hikvision products with similar zoom capabilities, the Dahua camera's Starlight technology gives it an edge in low - light performance, providing clearer images in dimly lit corridors or after office hours.

Intelligent Functions

Face Detection: The DH-SDT6C432-4P-GB-APV-0280 supports 6 attributes and 8 expressions, along with various face cutout and snapshot methods. In a small - office setting, this can be used for employee identification, access control, or monitoring visitor behavior. Some Hikvision models may have more complex face - detection setups, but Dahua's offering provides a user - friendly and efficient solution for small - office needs.
Perimeter Protection: This function automatically filters out false alarms caused by common distractions like animals or moving leaves. For small offices, it ensures that security alerts are accurate, reducing unnecessary disruptions. While Hikvision also offers perimeter protection features, Dahua's secondary recognition during target detection enhances alarm accuracy, providing a more reliable security measure.

The Dahua DH-SDT6C432-4P-GB-APV-0280 is a premium PTZ camera that combines cutting-edge technology with robust performance. Its multi-sensor design, AI-powered intelligence, and versatile applications make it an invaluable asset for modern surveillance systems. Whether deployed for public safety, traffic management, or commercial security, this camera delivers exceptional value and reliability. Invest in this innovative solution to enhance your security infrastructure and stay ahead of emerging threats.
